Nominal Capacity
Nominal output at capacity
Factory calibration mode
Linearity error
Repeatability
Zero return, creep (30 mins)
Temp, effect span/10°C
Temp, effect zero/10°C
Insulation resistance-brg to gnd
Insulation resistance-cbl to gnd
Excitation +ve
Signal +ve
*Sense +ve

50kg to 20t
2mV/V ± 0.1%
Compression
0.017%
0.01%
0.015%
0.01%
0.015%
> 5000 Mohms
> 1000 Mohms
RED
GREEN
BROWN*

Compensated temp. range
Output resistance
Input resistance
Service load
Safe load
Mechanical failure
Recommended excitation
Maximum excitation
Environmental protection
.
Excitation -ve
Signal -ve
*Sense -ve

-10° to 50° C
352.0 Ohms
410 Ohms nominal
100% of Rated Capacity
150% of Rated Capacity
> 300% of Rated Capacity
5 Volts to 15 Volts AC or DC
15 Volts DC
IP65 Standards
.
BLACK
WHITE
BLUE*
